Grid Properties: Ribbon Posting
When you display a grid, use this page to configure the posting for the
values of the grid. To define the number of decimals used in posting,
see the Colorbary/Histogram page.
Enable Posting
Show Posting: Toggle the defined postings on
and off.
Posting Parameters
Start Row for
Posting, Start Column for Posting/End
Row for Posting, End Column for Posting/Increment Row By, Increment
Column By: The starting, ending, and increment posting values
for the row and column parts of a grid. It is usually best to leave the
start and end at zero, as this implies to use the "start" and "end",
regardless of the number of traces.
Text Font, Text
Size, Text Color: These
define how the posting will appear. Select the font, specify the size,
and select a color.
Note: Fixed sized objects will remain the same regardless of the map scale. Variable sized objects will change size with the map scale.
